Pelican
Pelican Protector Case - Series 1560
SKU#: BD130
Ships via Standard Ground
Pelican 1560 Protector Case with wheels, IP67 rating, and military-grade protection for transporting sensitive equipment.
Looking for a quote? Simply add your items to the cart and choose Request for Quote during checkout.
Enter a value between 1 and 100000000 in increments of 1.
Earn Darley Dollars with this purchase
The Pelican Protector Case Series 1560 is a large, wheeled hard case built to protect sensitive equipment during transport through extreme and demanding environments. Manufactured in the USA, it delivers proven Pelican durability trusted since 1976.
Features
- Watertight: watertight, crushproof, and dustproof construction for maximum environmental protection
- Durable: open cell core with solid wall design for high strength and reduced weight
- Temperature-rated: engineered to perform in environments from -40°F to 190°F
- Material: polypropylene body designed for rugged, long-term use
Sealing and Pressure Control
- O-ring seal: silicone O-ring lid creates a reliable watertight seal
- Pressure valve: automatic pressure equalization valve balances interior air pressure while keeping water out
Mobility and Handling
- Wheels: strong polyurethane wheels with stainless steel bearings for smooth transport
- Trolley handle: retractable extension handle for easier rolling and maneuvering
- Grip: comfortable rubber over-molded top and side handles
Latches and Security
- Double-throw latches: easy open design that stays secure during drops and impact
- Padlock ready: stainless steel padlock protectors for added security
- Hardware: stainless steel hardware and pins for corrosion resistance
Interior and Customization
- Pick N Pluck foam: two-level Pick N Pluck foam with convoluted lid foam
- Foam material: 1.3 lb polyurethane foam for customized equipment fit
Standards and Protection Level
- Military-grade: designed to meet US and NATO mil-spec certifications
- IP rating: IP67 rated for protection against dust and water intrusion
- Warranty: backed by Pelican’s legendary lifetime guarantee where applicable by law
How is it used
This case is used to transport, store, and protect sensitive or valuable equipment during travel, field operations, and long-term storage in harsh conditions.
Intended for
Designed for professionals who require a mobile, high-capacity protective case for demanding military, industrial, and field applications.
Maintenance information
Regularly inspect and clean the O-ring seal, latches, wheels, and handles to maintain optimal performance and long-term protection.
Storage information
Store the case closed within the rated temperature range to preserve the seal, foam integrity, and wheel performance.
What is included
- Pelican Protector Case Series 1560
- Two-level Pick N Pluck foam
- Convoluted lid foam
- Exterior dimensions: 22.07 x 17.92 x 10.42 in
- Interior dimensions: 19.92 x 14.98 x 9.00 in
- Interior volume: 1.55 ft³
- Lid depth: 2.00 in
- Bottom depth: 7.00 in
- Total depth: 9.00 in
- Padlock hole diameter: 0.31 in
- Weight with foam: 20.00 lbs
- Weight without foam: 17.00 lbs
- Master pack weight: 21.00 lbs
- Buoyancy: 115.00 lbs
- Body material: polypropylene
- Latch material: ABS
- O-ring material: polymer
- Pin material: stainless steel
- Foam material: 1.3 lb polyurethane
- Purge body material: ABS
- Purge vent material: 3 micron hydrophobic non-woven
- Purge O-ring material: 70 shore nitrile
- Minimum temperature: -40°F
- Maximum temperature: 190°F
- Extendable handle: yes
- Wheels: 2
- Model: 1560
