PDW
PDW C100 Defense
SKU#: PDW001
PDW C100 Defense is a modular, long-endurance drone built for ISR, kinetic missions, and payload delivery with military-grade performance.
The PDW C100 Defense is a portable, packable small unmanned aerial system (sUAS) engineered for mission-critical operations. Designed for versatility and endurance, it supports long-range ISR (Intelligence, Surveillance, Reconnaissance), kinetic effects, and payload delivery. Built with military-grade components and Blue UAS-approved avionics, the C100 delivers unmatched performance in the field with hands-free autonomy and edge computing capabilities.
Features
- Interoperable Payloads: Supports a wide range of EO/IR, thermal, kinetic, and communications payloads for multi-domain operations.
- Long Flight Time: Up to 74 minutes with ISR payload, enabling extended mission coverage.
- High Payload Capacity: Carries up to 10 lbs with long endurance batteries.
- Speed Versatility: Cruise mode at 40.3 mph, with safe mode down to 4.9 mph for precision tasks.
- Low Acoustic Signature: 61dB at 5m, non-audible at 600m for stealth operations.
- Autonomy Features: Includes frontal collision avoidance and GNSS position hold for safe navigation.
- Weather Resistant: IP54-rated for durability in harsh environments.
- Night Operations Ready: Equipped with zero-light emission mode, IR LEDs, and strobe lights.
- High Wind Tolerance: Operates in sustained winds up to 30 mph and gusts up to 40 mph.
- Advanced Compute Core: Powered by Modal AI’s VOXL 1 Qualcomm 812 with optional Nvidia Xavier NX.
- Multi-Mission Capable: Configurable for ISR, kinetic effects, EW, and extended comms.
- Compact Design: Folds into a 24” x 15” x 8” form for easy transport.
How is it used?
Operators deploy the C100 Defense for reconnaissance, surveillance, target acquisition, and payload delivery. It can be configured for various mission profiles including ISR, cross-domain fires, and electronic warfare. Its autonomy features allow for hands-free operation, reducing cognitive load and enabling focus on mission execution.
Who uses it?
The C100 Defense is used by military units, special operations teams, and public safety agencies requiring a reliable, portable aerial system for tactical missions. Its modular design and universal payload integration make it ideal for warfighters and field operatives.
Maintenance information
Routine maintenance includes battery health checks, payload calibration, firmware updates, and inspection of propellers and motors. The system is designed for field-level servicing with modular components that can be easily replaced or upgraded.
Storage information
The C100 Defense folds into a compact 24” x 15” x 8” form factor, allowing it to be stored in a standard rucksack or protective case. It should be stored in a dry, temperature-controlled environment to preserve battery life and electronic integrity.
What is included?
- PDW C100 Defense
- Weight: 21.4 lbs (9.7 kg)
- Max Payload Mass: Up to 10 lbs (4.5 kg)
- Flight Time: 74 minutes with ISR payload
- Range: 6.2+ miles (10+ km)
- Cruise Speed: 40.3 mph (64.8 km/h)
- Max Speed: 40 mph (64.8 km/h)
- Wind Limits: Up to 40 mph gusts depending on payload
- Night Operations: Zero-light emission mode, IR LEDs, strobe lights
- Acoustic Signature: 61dB @ 5m
- Autonomy: Collision avoidance, GNSS hold
- Compute Core: VOXL 1 Qualcomm 812 + optional Nvidia Xavier NX
- Max Operational Altitude: 12,000 ft MSL
- Operational Temperature: -20˚C to 57˚C (-4˚F to 134.6˚F)
- Weatherization: IP54
- Supply Chain: NDAA Compliant / Blue UAS
- Imperial Units
- Folded: 24 in × 15 in × 8 in
- Unfolded: 64 in × 65 in × 11 in
- Metric Units
- Folded: 610 mm × 381 mm × 203 mm
- Unfolded: 1,626 mm × 1,651 mm × 279 mm
