The Mercury Quick Attack Monitor is a compact, portable firefighting monitor engineered to deliver high-volume water or foam streams while maintaining lightweight handling and rapid setup. It is the only portable monitor that meets both NFPA 1964 and EN‑15767‑1 standards.

Features

• Low-angle capability: Hits low at 10° to effectively attack fires close to the ground
• Extended reach: Improved reach up to 250 feet at 100 psi when paired with the Mercury nozzle (Style 4446)
• Lightweight construction: Compact design weighing only 15 lbs, or 19.6 lbs with FlowGuard
• High-flow performance: Rated flows up to 500 GPM (1900 LPM)
• Minimal friction loss: Low 6 psi friction loss at 500 GPM
• Certified performance: Meets NFPA 1964 and EN‑15767‑1 requirements
• Smooth operation: Easy open and close valve for fast control
• Secure transport: Strap attached with bag for easy stowing and transport
• Enhanced handling: Knurled handle for improved grip
• Debris protection: Handle wiper designed to minimize debris collection
• Wide elevation range: Elevation range from +10° to +50°
• Controlled rotation: Rotation range of ±20°
• High pressure rating: Maximum operating pressure of 230 psi, exceeding the 200 psi standard
• Crew safety option: Available with FlowGuard to help reduce hazard risk and increase crew confidence

How is it used?

The monitor is deployed directly at the scene and connected to a 2.5" water supply line. Once in position, the operator adjusts elevation and rotation to direct the stream, then opens the valve to deliver high-flow water or foam for structural firefighting applications.

Who used it?

The Mercury Quick Attack Monitor is used by firefighting professionals involved in structural firefighting operations who require a portable, high-performance monitor that can be quickly deployed and repositioned as conditions change.

Maintenance Information

Routine maintenance involves inspecting the valve, handle, and inlet and outlet connections for wear or debris, ensuring smooth movement of elevation and rotation components, and verifying that all seals and fittings remain in good condition.

Storage Information

When not in use, the monitor can be stored using the attached strap and bag. It should be kept in a clean, dry environment to help preserve materials and maintain reliable performance.

What is included

• Mercury Quick Attack LE Portable Monitor with attached strap and storage bag.

Need a custom configuration? Click the “Contact Us” button and a Darley sales representative will work with you to design the custom setup that fits your exact needs.
