Drop-In Style Booster Reel

Features

• Durable Construction: Made from high-grade materials to withstand heavy-duty use.
• Compact Design: Ideal for drop-in units or smaller apparatus compartments where space is limited.
• Smooth Operation: Electric model features chain and sprocket drive powered by an electric motor, while the manual model includes a cam-lock drag brake and removable direct crank rewind.
• Versatile Compatibility: Handles single 3/4" I.D. or 1" I.D. hose.
• High Capacity: Can hold up to 200' of 3/4" I.D. hose or 100' of 1" I.D. hose.

What is it?

The Hannay Reels Drop-In Style Booster Reels are compact, high-capacity hose reels designed for efficient hose management. They are available in both electric and manual versions to suit different operational needs.

How is it used?

These reels are used to manage hoses in various applications, ensuring smooth deployment and retrieval. The electric model uses a chain and sprocket drive powered by an electric motor, while the manual model uses a cam-lock drag brake and removable direct crank rewind for manual operation.

Who uses it?

These reels are used by professionals in firefighting, rescue operations, land and offshore drilling, and marine applications where reliable hose management is critical.

Tools Needed to Install

• Wrench set
• Screwdriver set
• Socket set
• Pliers

Installation Instructions

• Preparation
  • Ensure the reel is securely mounted and stable.
  • Gather all necessary tools and the reel components.
• Mounting the Reel
  • Position the reel in the designated mounting location.
  • Align the mounting holes on the reel with the corresponding holes on the mounting surface.
• Secure the Reel
  • Insert the bolts through the mounting holes and secure them with nuts.
  • Use a wrench or socket to tighten the bolts, ensuring the reel is firmly attached.
• Connecting the Hose
  • Attach the hose to the reel's inlet and outlet connections.
  • Ensure all connections are secure and leak-free.
• Testing the Operation
  • For the electric model, connect the power supply and test the motor operation.
  • For the manual model, test the crank rewind mechanism to ensure smooth operation.
• Maintenance Information
  • Regular Inspection: Periodically check for signs of wear or damage.
  • Cleaning: Keep the reel and hose clean from debris.
  • Lubrication: Apply appropriate lubricants to moving parts to maintain efficiency.

What is it used with?

The Hannay Reels Drop-In Style Booster Reels are used with hoses for various applications, including firefighting, rescue operations, and industrial settings.

Real-Life Examples

• Firefighting: Ensures quick deployment and retrieval of hoses during emergency situations.
• Marine Applications: Manages hoses for fluid transfer on ships and offshore platforms.
• Industrial Settings: Facilitates the handling of hoses for fluid transfer or pneumatic tools.

Material Used

• The reels are constructed from high-grade steel and durable polymers, providing resistance to harsh conditions and ensuring long-lasting performance.
